From a part that you can hold in your hand to a piece that weighs 20,000 lbs.
We have the experience and latest technology equipment to properly produce your part.
Mill-Turn Machines
These machines delivers maximum versatility for small to large parts. It combines the capabilities of a high-powered turning center and full-function machine center to produce parts in a single setup. We are capable of holding +/- 0.0003 on diameter and +/-0.0005 on location and size.
Details
| Brand | Model | Comments | |||||
|---|---|---|---|---|---|---|---|
| Okuma | Multus | Dual Spindle | X-25.50" | Y-11.80" | Z-78.74" | ||
| U4000 | Main Spindle | 4.41" thru | 15" chuck | 2800 RMP | |||
| 2SW/2000 | Sub Spindle | 10" chuck | 4200 RMP | ||||
| Mill Spindle | 12000 RMP | Full 5-Axis | |||||
| Lower Turret | 12 Station | Steady Rest Ready | |||||
| Mazak | 300 ll SY | Dual Spindle | X-24.00" | Y-9.00" | Z-38.00" | ||
| Main Spindle | 3" thru | 15" chuck | 1800 RMP | ||||
| Sub Spindle | 10" chuck | 3600 RMP | |||||
| Mill Spindle | 1000 RMP |
Horizontal Milling Machines
These machines allow for 3 sided part machining in a single set up, complex angle machining and finishing, and rapid production. The indexing pallet allows for 1 degree indexes of the work piece to quickly and properly finish your part. Utilizing our 2 pallet, 4 station system we can quickly and efficiently produce your parts.
Details
| Brand | Model | Axis | X-Axis Travel | Y-Axis Travel | Z-Axis Travel | Table Size(X/Y) | Comments |
|---|---|---|---|---|---|---|---|
| Makino | A55 | 4 | 22.00" | 22.00" | 22.00" | 15.50" X 15.0" | 2 Pallet / 4 Station Workcenter |
Four-Axis Machines
These machines allow for 3 sided part machining in a single set up, complex angle machining and finishing, and surface contouring. The live 4-axis table allows for contouring of inorganic surface profiles with high quality finishes.
Details
| Brand | Model | Axis | X-Axis Travel | Y-Axis Travel | Z-Axis Travel | Table Size(X/Y) | Comments |
|---|---|---|---|---|---|---|---|
| Mori Seiki | SV-503 | 4 | 40.20" | 20.10" | 20.10" | 52.00"/23.60" | 4-Axis Rotary Table |
| Hurco | VMX 64 | 4 | 63.95" | 34.00" | 29.00" | 66.00"/35.00" | Full 4-Axis/ Rotary Table 10,000 RPM |
Large Capacity Manual Turning Machines
Details
| Brand | Model | Type | Swing | Between Centers |
|---|---|---|---|---|
| Poreba | PL42-480 | Horizontal Lathe | 36" | 22' |
| Bullard | Vertical Lathe | 64" | 40" Z Axis |
CNC Mills
Our 4-axis machines can handle small to large size parts. Our largest table accommodates 126” by 90.5”. We specialize in complex CNC milling and can hold tolerances up to +/-0.0005” on our precision mills.
Details
| Brand | Model | Axis | X-Axis Travel | Y-Axis Travel | Z-Axis Travel | Table Size (X/Y) | Comments |
|---|---|---|---|---|---|---|---|
| Okuma | MB-66VB | 3 | 59.06" | 25.98" | 25.90" | 60.24"/25.98" | |
| Mori Seiki | SV-503 | 4 | 40.20" | 20.10" | 20.10" | 52.00"/23.60" | 4-Axis Rotary Table |
| Hurco | VMX 64 | 4 | 63.95" | 34.00" | 29.00" | 66.00"/35.00" | Full 4-Axis/ Rotary Table 10,000 RPM |
| Daewoo | DMV4020d | 3 | 40.00" | 20.00" | 24.00" | 47.25"/19.625" | 8,000 RMP |
| Fadal | VMC 15 | 3 | 20.00" | 16.00" | 19.00" | 26.00"/16.00" | 4 Machines / Short Run Production Cell Capable |
| Mazak | VTC-300C | 3 | 65.30" | 29.90" | 26.00" | 79.00"/20.00" | 10,000 RPM |
| Fadal | 6535 | 3 | 65.00" | 35.00" | 30.00" | 70.00"/35.00" | "50 Taper/ Renishaw Probe/ 8,000 RMP" |
| Laguna | MM ll STD | 25.00" | 13.00" | 12.00" | 54.00"/14.50" | 4,200 RMP | |
| Laguna | FTV-2 | 25.00" | 13.00" | 12.00" | 54.00"/14.50" | 3,300 RMP | |
| Trak-Mill | K3 | 25.00" | 13.00" | 12.00" | 54.00"/14.50" | 2 Machines |
CNC Lathes
Our many precision CNC lathes can handle up to 78” length and 35.5” diameter. With our 2- and 4-axis lathes, we can manufacture almost any type of machined part. Our live tool lathes allow any two machine operation part to be completed in one machine. We can mill, drill and tap in a single setup.
Details
| Brand | Model | Axis | Turrents | MAX Turning Diameter |
MAX Turning Length |
MAX RPM (Main Spindle) | Comments |
|---|---|---|---|---|---|---|---|
| Okuma | LB-3000 | 3 | 1 | 16.54" | 60.71" | 3300 | Live Tooling |
| Mazak | Nexus 350 ll MM |
3 | 1 | 16.54" | 60.71" | 3300 | Live Tooling |
| Okuma | LB-45 ll M | 3 | 1 | 25.59" | 39.37" | 2400 | Live Tooling |
| Okuma | LU-300 | 4 | 2 | 14.57" | 23.62" | 3800 | |
| Okuma | LB-45 | 2 | 1 | 35.50" | 78.00" | 1800 | 35.5" Outer Chuck |
| Mazak | QT-30 | 2 | 1 | 15.00" | 40.00" | 4200 | |
| Okuma | LB-25 | 2 | 1 | 9.84" | 20.00" | 3500 | |
| Mazak | Nexus 200 | 2 | 1 | 8.00" | 19.00" | 5000 | 2 Machines / Short Run Production Cell Capable |
Manual Milling Machines
Details
| Brand | Model | Type | X-Axis Travel | Y-Axis Travel | Z-Axis Travel | Comments |
|---|---|---|---|---|---|---|
| Lucas | 542B 120 | Boring Mill | 3" each way 6" travel" |
48" x 120" table 90" Head 40,000 lb. Capacity |
||
| Ayce | 3 1/2 | Boring Mill | 60" | 60" | 26" | |
| York Portable | 4-14 ET | Boring Mill | 2" to 10" dia | |||
| Alliant | RT2 | Knee Mill | 42" | 9" | 9" | |
| Alliant | FTV-4L | Knee Mill | 42" | 9" | 9" | 2 machines |
| Bridgeport | Series 2 | Knee Mill | 42" | 9" | 9" | 2 machines |
| Lagun | FTV-4L | Knee Mill | 42" | 9" | 9" |
Manual Turning Machines
Details
| Brand | Model | Type | Swing | Between | Centers |
|---|---|---|---|---|---|
| Bullard | Vertical Lathe | 64" | 40" Z Axis | ||
| Moriselki | MS-1500G | Engine Lathe | 23" | 53" between centers | |
| Hwacheon | HL630 | Engine Lathe | 25" | 118" between centers | |
| Hwacheon | Engine Lathe | 18" | 59" between centers |
Service Grinders
Details
| Brand | Model | Axis | X-Axis Travel | Y-Axis Travel | Z-Axis Travel | Table Load | Comments |
|---|---|---|---|---|---|---|---|
| Thompson | 6C-818279 | 3 | 72.00" | 20.00" | 28.00" | 2000 lbs. | |
| Okamoto | ACC12-24 EXB | 3 | 24.00" | 12.00" | 12.00" | 925 lbs. | Self Dressing |
| Okamoto | ACC12-24 DX | 3 | 24.00" | 12.00" | 12.00" | 925 lbs. | |
| Acer | AGS-1224 AHD | 3 | 24.50" | 14.00" | 12.00" | 1000 lbs. max | |
| Walker Ceramax | H 618 | 3 | 18.00" | 6.00" | 12.00" | 125 lbs. |
Blanchard Grinders
Details
| Brand | Model | Height | Diameter | Work Load |
|---|---|---|---|---|
| BLG2-16 | 44516 | 12.00" | 16.00" | 1000 lbs. |
| BLG1-42 | 22 | 12.00" | 42.00" | 2000 lbs. |
| BLG3-36 | 18ck | 11.00" | 36.00" | 3000 lbs. |
MISC Machines
- Long Bead Broach
- Iron Worker
- Black Oxide
- Heat Treat Ovens
- Portable Boring Mill
